Electric Hoist: 1 Tonne, 240 Volt

More From This Brand

Add to New List

• Product Info

• This Duke 240v Hoist has a WLL (weight load limit) of 1 tonne. It operates at 240 volts (50hz single phase), making it ideal for light industrial use

  Various lift heights are available, ranging from 3mtr - 20mtr (select from drop-down list). This product has a lifting speed of 2.5 metres per minute

  When powering from a generator you will need a 3.9kw Genset

  Our 240v hoist is lightweight and compact, making it easy to transport and suitable for a number of different lifting applications. The heavy-duty modular design also makes upkeep of the hoist very easy, while also extending the overall service life of the product

  This hoist comes supplied with:

  • A 3 mtr* pendant control with emergency stop
  • A chainbag
  • A power supply cable and plug (5mtrs)
  • Swivel bottom hook

  The duty cycle of the hoist is 30%, which means that it can be used for a maximum of 20 minutes' continued operation in a 1 hour period

  Current at rated load (amp): 4

  The frame and control enclosure provide protection against dust and water ingress, plus we also offer a weather protection jacket for a small additional cost. It has an official enclosure rating of IP54

  The 240v 1 tonne hoist is supplied fully tested and certified, and comes with a 12 month warranty

  Please view our full selection of electric hoists before making your selection. Make sure you have chosen the correct WLL for your needs

  *Please contact us if you require a longer pendant



• Specifications
• Brand Duke

  Custom Made Product Yes

  Included in Return Policy No

  Additional Information

  Catalogue Information Hook Dimensions Operation Manual
