ActionRam 100tonne, 150mm Stroke Hydraulic Cylinder

More From This Brand

Add to New List

• Product Info

• ActionRam Hydraulic Cylinder

  Model: HHYG-100150

  Capacity: 100tonne

  Stroke: 150mm

  Open height: 432mm

  Closed Height: 282mm

  Oil capacity: 2335cc

  Effective area: 153.9cm²

  Outside diameter: 178mm

  Chrome plated Cylinder and Ram

  Spring Return

  Maximum pressure 700BAR

  Fitted with female coupling

  Can be used in any position

  Fully tested before dispatch

  12 months warranty

  Recommended Hand Pump to operate this is HHB-700S-3000cc

• Specifications
• Brand ActionRam

  Product Weight 49.2kg

  Product Colour Black & Yellow

  W.L.L. 100tonne

  Stroke 150mm

  Inside Diameter / Bore 135mm

  Oil Capacity 2335cc

  Maximum Operating Pressure 700bar

  Open Height 432mm

  Closed Height 282mm

  Acting Single Acting Cylinder

  Available for Hire Yes

  Warranty 12 Months

  Custom Made Product No

  Included in Return Policy Yes

  Third Party Supplied No

  Additional Information

  Data Sheet Instruction Manual
• Price Breaks
• ActionRam 100 tonne x 150mm stroke hydraulic cylinder (Net Weight Per Item: 49.20kg):

  Quantity:

  1+

  (£619.49 inc VAT)
